4.25
ELECTRONIC FUEL INJECTION
4
Fuel Tank Removal
IMPORTANT: Syphon as much fuel from the tank as
possible before attempting to remove it from the
vehicle.
1. Remove the driver and passenger seats along with the rear
service panel.
2. Disconnect the negative battery cable from the battery
located under the driver’s seat.
3. While holding a shop towel over the fuel line connector,
disconnect the quick connect fuel line from the fuel pump.
Move fuel line out of the way for tank removal.
NOTE: A small amount of fuel may come out of the
fuel line or tank. Properly drain fuel into a suitable
container.
4. Disconnect the fuel pump electrical harness.
5. Remove the fuel tank vent hose clamp with a suitable pliers.
Remove the vent line from the fuel tank vent fitting.
6. Remove the rear seat base assembly from the vehicle by
removing the (2) fasteners from the rear seat base.
7. Remove the shift knob and the center console from the
vehicle.
Always wear safety goggles when working with
high pressure or flammable fluids. Failure to do so
could result in serious injury or complications.
