5.22
BODY / STEERING / SUSPENSION
REAR STABILIZER BAR
Removal / Installation
1. Remove the exhaust pipe and exhaust silencer from the
vehicle.
NOTE: The exhaust silencer can be removed
through the side of the vehicle after the exhaust pipe
is detached from the header pipe.
2. Remove the fastener retaining the stabilizer bar to the
linkage on each side of the vehicle.
3. Remove the (4) fasteners retaining the stabilizer bar to the
bracket.
4. Remove the stabilizer bar from the bracket (bracket can
remain attached to the frame).
5. Inspect the stabilizer bar for straightness. Inspect the
bushings and replace if needed.
6. Reverse the procedure for installation. Torque the stabilizer
bolts to 18 ft. lbs. (24 Nm).
Remove
Fasteners
Leave bracket
attached to frame.
Stabilizer Bar
Grease
Zerk
Bushings
Bracket
Linkage
18 ft. lbs.
(24 Nm)
Nuts
To Next Page
