7.9
FINAL DRIVE
7
21. Position the boot lip in its groove. Install and secure the
boot with the large clamp using the “earless” clamp pliers.
Drive Shaft Installation
1. Install new spring ring on drive shaft. Apply an anti-seize
compound to splines.
2. Align splines of drive shaft with front gearcase and reinstall
the drive shaft. Use a rubber mallet to tap on the outboard
end of the drive shaft if necessary
3. Install drive shaft into the front bearing carrier.
4. Install the upper ball joint end into the front bearing carrier.
CV Boot Clamp Pliers
Earless Type: 8700226
FRONT DRIVE SHAFT
Grease Capacity
80 Grams
Grease Capacity
80 Grams
Plunging
Joint
CV Joint
Apply
Anti-Seize
NEW
Spring Ring
To Next Page
