Polaris Ranger RZR SW User Manual

10.21
ELECTRICAL
10
Relay Operation
Located in the fuse box under the dash, the relays assist with
component operation like the cooling fan, fuel pump and EFI
system.
NOTE: The Rear Diff Solenoid Relay is mounted
separately, attached to the rear plastic LH panel
divider behind the driver’s seat.
NOTE: The Blackout Relay is secured to the wire
harness near the fuse box.
CHASSIS RELAY provides power to the following systems:
• Lights (Headlights / Taillights / I.R. Lights / Blackout
Circuit)
• Drive (AWD / TURF)
• Accessory (12V Recepticles / Accessory Options)
EFI RELAY provides power to the following systems:
• Fuel Injectors
• Cam Phase Sensor
• Ignition Coil
•Fan Relay
• Fuel Pump Relay
FAN RELAY provides power to the following system:
•Fan Motor
FUEL PUMP RELAY provides power to the following
system:
• Fuel Pump
REAR DIFF SOLENOID RELAY provides power to the
following system:
• Rear Differential Solenoid
CHASSIS RELAY
COLOR FUNCTION
Red
30-Amp fuse protected 12 Vdc
constant battery voltage.
Brown Relay coil ground.
Orange
ECU 12 Vdc power input to enable
relay.
White
Provides 12 Vdc power for lights, drive
and accessory circuits.
EFI RELAY
COLOR FUNCTION
Red / White
20-Amp fuse protected 12 Vdc
constant battery voltage.
Dark Green / Yellow ECU ground input to enable relay.
Red / White
20-Amp fuse protected 12 Vdc
constant battery voltage.
Red / Dark Blue
Provides 12 Vdc power for EFI system
circuits.
FAN RELAY
COLOR FUNCTION
Red
20-Amp circuit breaker protected 12
Vdc constant battery power.
Orange / White ECU ground input to enable relay.
Red / Dark Blue 12 Vdc switched power from EFI relay.
Orange / Black
Provides 12 Vdc power for fan
operation.
FUEL PUMP RELAY
COLOR FUNCTION
Red / Light Green
10-Amp fuse protected 12 Vdc battery
voltage.
Dark Green / Yellow ECU ground input to enable relay.
Red / Dark Blue
BUS Bar - 12 Vdc switched power
from EFI relay.
Red / Light Blue
Provides 12 Vdc power for fuel pump
operation.
REAR DIFF SOLENOID RELAY
COLOR FUNCTION
Red / Dark Green
10-Amp fuse protected 12 Vdc battery
voltage.
Dark Green / White ECU input to enable relay.
Brown Relay coil ground.
Red
Relay switched power to operate the
Rear Diff Solenoid.
Blue
Ground to energize the Rear Diff
Solenoid.
