Polaris Ranger RZR SW User Manual

5.14
BODY / STEERING / SUSPENSION
STEERING ASSEMBLY
Exploded View
Boot
Rod End
Tie Rod
RH Boot
LH Boot
Spacer
Bearing
Steering Wheel
Cap
Pivot Tube
Steering Shaft
Cotter Pin
Gear Box
Bearing
Bushing
Oil Locking
Shock Asm.
Asm.
17 ft. lbs.
(23 Nm)
17 ft. lbs.
(23 Nm)
12-14 ft. lbs.
(16-19 Nm)
Nut
42.5 ft. lbs.
(58 Nm)
42.5 ft. lbs.
(58 Nm)
12-14 ft. lbs.
(16-19 Nm)
27-33 ft. lbs.
(37-45 Nm)
25-31 ft. lbs.
(34-42 Nm)
23 ft. lbs.
(31 Nm)
23 ft. lbs.
(31 Nm)
7 ft. lbs.
(10 Nm)
12 ft. lbs.
(16 Nm)
Bushing
Thick
Washer
Thin
Washer
Thick
Washers
Thin
Washer
Thin
Washer
Spacer
