10.17

ELECTRICAL

TAIL / BRAKE LIGHTS

Bulb Replacement

Before replacing the bulb(s), use a digital multi-meter to test the

harness to ensure the lamp is receiving 12 volts and that a ground

path is present.

If a tail light or brake light does not work the bulb may need to

be replaced.

1. Remove bulb by turning the rubber base 1/4 turn and

pulling the bulb out. Replace it with recommended bulb.

Apply Dielectric Grease (PN 2871329).

2. Test the tail light and brake light to verify it is working

properly.

Tail / Brake

Light
