ELECTRONIC FUEL INJECTION
System Power
(Battery Potential / Power Input)
Voltage Too High
168
3
P0563
C1063
Voltage Too Low 4
P0562
C1064
Engine Speed (This is applicable
when the EPS module gets the
engine speed from the ECM)
Received Engine Speed Has Error 190 19 C1066
Gear Sensor Signal Voltage Too Low 523 4 P0916
ECU Memory EEPROM: Read/Write Failure 628 12 C1073
Crankshaft Position Sensor (CPS) Plausibility Fault 636 2 P0335
Camshaft Phase Sensor Circuit Fault 637 8 P0340
Injector 1 (MAG)
Driver Circuit Open / Grounded
651
5 P0261
Driver Circuit Short to B+ 3 P0262
Driver Circuit Grounded 4 P1262
Injector 2 (PTO)
Driver Circuit Open / Grounded
652
5 P0264
Driver Circuit Short to B+ 3 P0265
Driver Circuit Grounded 4 P1265
Rear Differential Output
Driver Circuit Open / Grounded
746
5 P1691
Driver Circuit Short to B+ 3 P1692
Driver Circuit Grounded 4 P1693
Fan Relay Driver Circuit
Driver Circuit Open / Grounded
1071
5 P1481
Driver Circuit Short to B+ 3 P1482
Driver Circuit Grounded 4 P1483
Ignition Coil Primary Driver 1 (MAG) Driver Circuit Short to B+ 1268 3 P1353
Ignition Coil Primary Driver 2 (PTO) Driver Circuit Short to B+ 1269 3 P1354
Fuel Pump Driver Circuit
Driver Circuit Open / Grounded
1347
5 P0230
Driver Circuit Short to B+ 3 P0232
Driver Circuit Grounded 4 P0231
ECU Output Supply Voltage 1
Voltage Too High
3597
3 P16A2
Voltage Too Low 4 P16A1
ECU Output Supply Voltage 2
Voltage Too High
3598
3 P16A9
Voltage Too Low 4 P16A8
All Wheel Drive Control Circuit
(AWD)
Driver Circuit Open / Grounded
520207
5 P1836
Driver Circuit Short to B+ 3 P1835
Driver Circuit Grounded 4 P1834
Steering Over Current Shut Down Current Above Normal or Grounded 520221 6 C1050
Steering Excessive Current Error Current Above Normal or Grounded 520222 6 C1051
Steering Torque Partial Failure Condition Exists 520223 31 C1052
DIAGNOSTIC TROUBLE CODE TABLE
Component Condition SPN FMI
Digital Wrench™
P-Code
