4.44
ELECTRONIC FUEL INJECTION
2. Connect the SmartLink Module cables to the PC and
vehicle. See “Digital Wrench™ - Diagnostic Connector”
on page 4.40.
3. Open the Digital Wrench™ program.
4. Select the model year, product line and vehicle description
by selecting the “Change Vehicle Type” icon.
5. Select the “Special Tests” icon.
6. Select “Engine Controller Reprogramming”.
7. Select the file you want to load into the ECU then click the
“Continue” icon to proceed to the Integrity Check.
8. Follow the on screen instructions and connect a 9V battery
to the reflash battery connector located off the main
diagnostic connector. Click the “Continue” icon to obtain
a Request Code.
