Polaris Ranger RZR SW User Manual

1.5
GENERAL INFORMATION
1
MODEL: 2011 RANGER RZR SW
MODEL NUMBER: M11VE76AA
ENGINE NUMBER: 1204276
CLUTCH CHART
Engine
Platform
H.O. Domestic Twin Cylinder,
Liquid Cooled, 4-Stroke
Engine Number 1204276
Engine Displacement 760cc H.O.
Number of Cylinders 2
Bore & Stroke (mm) 80 x 76.5 mm
Compression Ratio 11:1
Compression Pressure 165 - 185 psi
Engine Idle Speed 1250 ± 200 RPM
Engine Max Operating RPM 6600 ± 200 RPM
Lubrication Pressurized Wet Sump
Oil Requirements PS-4 Plus Synthetic
Oil Capacity 2 qts. / 1.9 liters
Coolant Capacity 4.8 qts. / 4.5 liters
Overheat Warning Instrument Cluster Indicator
Exhaust System Dual Headpipe / Single Silencer
Fuel System
Fuel System Type Bosch M17 EFI
Fuel Delivery Electronic Fuel Pump (in tank)
Fuel Pressure 45
± 2 psi (310 ± 14 kPa)
Fuel Filters See Chapter 4
Fuel Capacity / Requirement
7.25 gal. (27.4 liters)
87 Octane (minimum)
Electrical
Alternator Max Output 500 Watts @ 3000 RPM
Headlights 2 - Halogen: Low 55 W / High 60 W
Tail / Brake 2 - 6 Watts / 2 - 27 Watts
Starting System Electric Start
Ignition System Bosch M17 (ECU Controlled)
Ignition Timing (Variable) 3
° - 10° BTDC @ 1200 RPM
Spark plug / Gap RC7YC3 / .035 in. (0.9 mm)
Battery
Yuasa YTX20HL /
18 Amp Hr. / 310 CCA / 12 Volt
Instrument Type Multifunction Instrument Cluster
DC Outlet (2) Standard 12 Volt
Relays
Chassis / EFI / Fan
Fuel Pump / TURF / Blackout
Circuit Breaker Fan Motor: 20 Amp
Fuses
Lights: 20 Amp
Fuel Pump: 10 Amp
Drive: 10 Amp
EFI: 20 Amp
Accessory: 20 Amp
Drivetrain
Transmission Type Polaris Automatic PVT
Drive Gear Ratio - Front Output
Reverse
Low
High
8.3398:1
7.1474:1
2.8226:1
Drive Gear Ratio - Rear Output
Reverse
Low
High
27.0003:1
23.1398:1
9.1381:1
Shift Type In Line Shift - H / L / N / R / P
Front Gearcase
Fluid Type / Capacity
Polaris Demand Drive Plus
6.75 oz. (200 ml)
Transmission: Main Gearcase
Fluid Type / Capacity
Polaris AGL Plus
24 oz. (710 ml)
Transmission: Transfer Case
Fluid Type / Capacity
Polaris AGL Plus
14 oz. (414 ml)
Rear Gearcase
Fluid Type / Capacity
Polaris Premium ADF
22 oz. (650 ml)
Belt 3211133
Steering / Suspension
Front Suspension / Shock
Independent Dual A-arm
FOX
™ 2.0 Piggyback
Front Travel 12 in. / 30.5 cm
Rear Suspension / Shock
Rolled IRS w/Anti-Sway Bar
FOX
™ 2.0 Piggyback
Rear Travel 12 in. / 30.5 cm
Shock Preload Adjustment
Front / Rear
Threaded Spanner Wrench
Adjustment
Toe Out 1/8 - 1/4 in. (3 - 6.4 mm)
Wheels / Brakes
Front Wheel Size
Front Tire Type / Size
12 x 6 / Steel
Maxxis Bighorn / 26 x 9 R12
Rear Wheel Size
Rear Tire Type / Size
12 x 6 / Steel
Maxxis Bighorn / 26 x 9 R12
Tire Air Pressure - Front / Rear 18 psi (124 kPa)
Brake - Front / Rear
Foot Actuated - 4 Wheel
Hydraulic Disc
Brake Fluid DOT 4
Altitude
Shift
Weight
Drive
Spring
Driven
Spring
Meters
(Feet)
0-1500
(0-5000)
23-62
(5632337)
Black
(7043594)
Blk / Almond
(7043167)
1500-3700
(5000 - 12000)
23-58
(5632218)
Black
(7043594)
Blk / Almond
(7043167)
