Printronix P5000 - Page 135

Adjustments and Tests
135
Legend:
1) Timing Belt Shield
2) Motor Mount Bolt (2)
3) Paper Feed Drive Motor
4) Splined Shaft
Figure 10. Paper Feed Timing Belt Adjustment
1/8 inch
Direction of Force
1
2
3
4
2
A
A
