Chapter 5 Section I: Replacement Procedures
Shaft, Support
Removal
1. Prepare the printer for maintenance (page 132).
2. Unlock the tractors and slide them to the far right.
3. Remove the paper supports from the splined shaft and support shaft.
(See page 240, item 4.)
4. Remove the screw securing the right tractor shaft plate and remove the
plate (page 240, items 7 and 8)..
NOTE: Hold the tractors while removing the support shaft.
5. Slide the support shaft to the right, out of the tractors and the right side
plate. (See page 240, items 9, 10, and 11.)
Installation
1. Slide the support shaft into the right side plate and through the lower
holes in the tractors. (See page 240, items 9, 10, and 11.)
2. Slide the support shaft through the left side plate until it bottoms in the left
tractor shaft plate. (See page 240, items 2 and 9.)
3. Install the right tractor shaft plate and screw (page 240, items 7 and 8) by
first sliding the upper “fingers” up and against the flange on the ball
bearing, then sliding the rectangular cutout over the support shaft end,
then snapping the U-shaped “spring” behind
the tab on the right side
plate.
4. Install the paper supports to the splined shaft and support shaft. (See
page 240, item 4.)
5. Return the printer to normal operation (page 133).
