Chapter 5 Section I: Replacement Procedures
Cover Assembly, Shuttle
Removal
1. Prepare the printer for maintenance (page 132).
2. Loosen the shuttle cover screws (page 230, item 2).
3. Grasping the edges of the shuttle cover assembly, tilt the rear edge up
and lift the shuttle cover assembly out of the printer.
Installation
1. Place the shuttle cover assembly in the printer. Tilt the forward edge of
the cover down slightly and work the cover into position.
NOTE: Make sure the holes in the cover are over the locating pins on the
base casting.
2. Tighten the shuttle cover screws (page 230, item 2).
3. Return the printer to normal operation (page 133).
