Chapter 5 Section I: Replacement Procedures
Fan Assembly, Cabinet Exhaust
NOTE: This procedure applies only to cabinet models.
Removal
1. Prepare the printer for maintenance (page 132).
2. Open the front and rear cabinet doors and the printer cover.
3. Remove the paper fence/paper tray assembly. (See page 224.)
4. Remove the two 1/4 inch screws securing bottom of the air exhaust duct.
(See page 226, item 4).
5. Remove the 1/4 inch screw directly below the forms thickness lever.
6. Disconnect the fan cable connector from connector P307 and remove the
air exhaust duct.
7. Disconnect the fan cable connector from the side of the air exhaust duct.
8. Remove the two 1/4 inch fan mounting screws and the cabinet exhaust
fan assembly.
Installation
CAUTION
Air flow is DOWN. Install the cabinet exhaust fan so the label on the fan
faces down.
1. Reverse steps 2 through 8 of the removal procedure.
2. Return the printer to normal operation (page 133).
