Chapter 5 Section I: Replacement Procedures
Circuit Breaker
Removal
1. Prepare the printer for maintenance (page 132).
2. Remove the card cage fan (page 183).
3. Disconnect the four circuit breaker electrical leads.
(Cabinet Models: See page 246.
Pedestal Models: See page 234.)
4. Press in on the spring clips and remove the circuit breaker from the
printer.
Installation
1. Press the circuit breaker into the cutout until the spring clips snap into
place.
(Cabinet models: See page 246.
Pedestal models: See page 234.)
CAUTION
To prevent severe damage to the printer, the circuit breaker electrical
leads must be connected correctly.
2. Connect the four circuit breaker electrical leads.
(Cabinet Models: See page 246.
Pedestal Models: See page 234.)
3. Install the card cage fan (page 183).
4. Return the printer to normal operation (page 133).
