Chapter 5 Section I: Replacement Procedures
Shaft, Splined
NOTE: The barrier panel must remain installed and fastened during this
procedure.
Removal
1. Prepare the printer for maintenance (page 132).
2. Remove the paper supports from the splined shaft and support shaft.
(See page 240, item 4.)
3. Remove the paper feed timing belt (page 168).
4. Unlock the left and right tractors and slide them to the center of the shaft.
5. Remove the screw securing the right tractor shaft plate and remove the
plate (page 240, items 7 and 8).
6. Slide the splined shaft out of the sealed ball bearing in the left tractor shaft
plate and remove the tolerance ring from the left end of the splined shaft
(page 240, items 3, 5, and 6).
7. Hold the tractors so they do not fall, grasp the vertical adjustment knob,
and slide the splined shaft to the right, out of the tractors and side plate.
