Control Panel Assembly, Cabinet Models
173
Control Panel Assembly, Cabinet Models
Removal
1. Prepare the printer for maintenance (page 132).
2. Disconnect RJ11 connector P310 from connector J310 on the control
panel.
3. Loosen four screws securing the control panel to the control panel
bracket. (See page 226, item 1.)
4. Remove the control panel assembly from the keyways in the control panel
bracket.
Installation
1. Position the control panel assembly on the bracket, engage the mounting
screws in the keyways, and hand tighten the screws. (See page 226, item
1.)
2. Connect RJ11 connector P310 to connector J310 on the control panel.
3. Lower the printer cover and center the control panel assembly in the
cutout of the printer cover.
4. Open the printer cover and tighten the four control panel mounting
screws.
5. Return the printer to normal operation (page 133).
