Printronix P5000 - Dashpot

180
Chapter 5 Section I: Replacement Procedures
Dashpot
CAUTION Two persons may be required to do this procedure. Prop or hold the
printer cover securely while disengaging the dashpot.
NOTE: This procedure applies only to cabinet models.
Removal
1. Prepare the printer for maintenance (page 132).
2. Open the cabinet rear door.
3. Pry back the spring retaining clips. (See Figure 34, page 226.)
4. Remove the dashpot from the ball studs.
Installation
CAUTION The dashpot must be installed with the large cylinder uppermost.
Two persons may be required to do this procedure. Prop or hold the
printer cover securely while installing the dashpot.
1. Position the dashpot against the ball studs on the upper and lower
brackets with the large cylinder uppermost. (See Figure 34, page 226.)
2. Using external grip ring pliers to spread the retaining clips, push the
dashpot onto the ball joints and slide the spring clips over the top (bottom)
of the ball joint into the retaining grooves.
3. Close the printer cover.
4. Return the printer to normal operation (page 133).
