Stacker Problems
The power stacker augments the paper feed system of the printer. The most
frequently occurring problems in the paper feed system are paper jams.
Because of the electromechanical nature of the system, other problems that
can occur are worn or poor electrical connections and cabling, worn or
defective feed motors, worn or damaged mechanical components, or
incorrect installation of the stacker assembly. Table 6 shows some of the
problems that can occur with the power stacker and the page where you can
find the troubleshooting procedure.
Table 6. Power Stacker Problems
Symptom Origin of Symptom Explanation Solution
Printer does not detect
presence of power
stacker
Reported by customer. Various causes possible. page 96
STACKER FAULT Message on control
panel LCD.
This message is triggered
when the elevator cannot
reach the top or bottom limit
switch before timing out.
page 83
STACKER FULL Message on control
panel LCD.
Status message: the power
paper stacker is full.
page 84
STACKER JAM Message on control
panel LCD.
Paper is bunching above the
elevator or the paper motion
detector is not working
properly.
page 85
Stacker “chatters” at
upper or lower limit
Reported by customer. Various causes possible. page 97
Stacker does not stack
properly
Reported by customer. Various causes possible. page 98
Stacker elevator does
not move
Reported by customer. Various causes possible. page 98
Stacker elevator moves
by itself
Reported by customer. Various causes possible. page 98
Stacker limit switch
check
Other troubleshooting
procedures.
A procedure that tests the
motion limit switches at the
top and bottom of the vertical
rails. You will usually be
referred to this procedure
from other troubleshooting
procedures. When you have
completed this procedure,
return to the procedure that
sent you there.
page 99
