Chapter 5 Section I: Replacement Procedures
Control Panel Assembly, Pedestal Models
Removal
1. Prepare the printer for maintenance (page 132).
2. Open the printer cover.
3. Loosen the four captive screws until the control panel is released from the
printer top cover. (See page 228, item 2.)
4. Remove the two 5/16 inch screws securing the control panel ground
straps. (See page 228, item 11.)
5. Lift the control panel and disconnect the RJ11 cable connector from the
control panel assembly.
6. Remove the control panel assembly.
Installation
1. Reverse steps 2 through 6 of the removal procedure.
2. Return the printer to normal operation (page 133).
