Chapter 5 Section I: Replacement Procedures
Paper Feed Motor
Removal
1. Prepare the printer for maintenance (page 132).
2. Cabinet Models: Remove the paper path (page 199).
Pedestal Models: Remove the top cover assembly (page 179).
3. Cabinet Models: Loosen four screws and remove the barrier shield. (See
page 230, items 3, 4, and 9.)
Pedestal Models: Loosen the four screws and remove the barrier shield
and paper guide. (See page 232, items 3, 4, and 5.)
4. Remove the timing belt cover by squeezing the front and back to release
the plastic tabs from the slots in the side plate (page 230, item 7).
5. Loosen, but do not remove, the two 5/16 inch paper feed motor mounting
screws. (See page 244, item 10.)
6. Roll the paper feed timing belt off the paper feed motor pulley and splined
shaft pulley.
7. Trace the paper feed motor cables back to the controller board, releasing
it from tie wraps. (See the cable routing diagrams in Appendix A.)
8. Disconnect connector P107 from the controller board and remove the
paper feed motor connector from connector P107. (See page 172.)
NOTE: Some paper feed motors are mounted with nuts and bolts; other
motors have threaded flanges, eliminating the need for nuts.
9. Remove the motor mount screws (and nuts, if present).
10. Remove the paper feed motor assembly.
