10/100Base-T LEDs And DIP Switches
195
Table 5. 10/100Base-T DIP Switch Settings
DIP Switch
Description
12
OFF
(up)
OFF
(up)
Normal operation. With both DIP switches in the “OFF”
position, the interface boots up using the settings in
flash memory rather than the default settings.
ON
(down)
OFF
(up)
Factory default settings. With the DIP switches in this
configuration, the interface boots up and all settings
stored in flash memory are erased except the ethernet
address and key value.
OFF
(up)
ON
(down)
Default IP. With the DIP switches in this configuration,
the interface boots up with factory default settings, but
the stored settings in flash memory remain intact.
Setting DIP switch 2 to “ON” does not clear any
settings stored in flash memory, it boots the unit in a
different state with the settings in flash memory
temporarily ignored.
ON
(down)
ON
(down)
If the interface is connected to a network with link
integrity and then reset to MOS, a download will be
forced. If the unit is not connected to a network, it will
print a test page.
