302
Appendix A
Cable Assembly, Control Panel (P/N 152440-901)
PIN 1
PIN 1
PIN 8
PIN 8
(Gray)
(Brown)
(Gray)
(Brown)
NOTE: If you replace the control panel cable,
you must install two ferrite shielding beads.
See Appendix D.
