Printronix P5000 - Page 141

Adjustments and Tests
141
Legend:
1) Forms Thickness Lever
2) Feeler Gauge
3) Hammer Bank Cover
4) Ribbon Mask
5) Setscrew, 3/32 inch hex (2)
Figure 13. Platen Gap Adjustment
A
A
NOTE: Left side adjustment
shown. Right side is the same.
1
2
3
4
5
