Printronix P5000 - Page 17

How To Identify A Printer
17
Figure 1. How to Interpret Model Numbers
Printronix Line
Matrix Printer
P5000 Printer
P5005B-12-QA
Housing Code:
0 = Pedestal
1 = Table Top
2 = Floor Cabinet
Speed Rating:
05 = 475 lpm
1
05A = 500 lpm
1
05B = 500 lpm
08 = 800 lpm
1
09 = 900 lpm
1
10 = 1000 lpm
12 = 1200 lpm
1
14 = 1400 lpm
1
15 = 1500 lpm
20 = 2000 lpm
2
24 = 2400 lpm
2
KA = P5XKA printer
1
06H = H-Series printer with 102-hammer shuttle
03H = H-Series printer with 60-hammer shuttle
1
Model not covered in this manual. Refer to Maintenance Manual 164253-001.
2
Model not covered in this manual. Refer to Maintenance Manual 173843-001.
Optional 12 MIL (0.012 inch) hammer tips.
Standard tips are 16 MIL (0.016 inch). This
option does not apply to H-Series printers,
which have unique hammer spring
assemblies.
QA = Pedestal model with optional Quick-Access cover
SS = Cabinet model with optional SureStak™ power
paper stacker.
