Chapter 5 Section I: Replacement Procedures
Installation
CAUTION
To prevent electrostatic damage to electronic components, always wear
a properly grounded static wrist strap when you handle circuit boards.
IMPORTANT
P5X05B, P5X10, and P5X15 printers take the 40 MHz CMX controller
board. P5006H, P5206H, P5003H, and P5203H printers take the CFX
controller board.
1. Position the controller board in the card cage, shield side down,
component side up. Engage the screw on the bottom of the card cage in
the keyway in the controller shield. Slide the board to the right until the
serial cable connector J201 on the controller board lines up with the
cutout in the card cage. (See page 236.)
2. Tighten the two screws securing the controller shield near serial cable
connector J201.
3. Tighten the screw securing the controller shield to the bottom of the card
cage.
4. Connect all cable connectors to the controller board, using the
Interconnection Diagram in Appendix A as your guide.
5. Install the expansion-CT board, if necessary (page 181).
6. Install the NIC, if necessary (page 192).
7. Cabinet Models: Install the paper path (page 199).
Pedestal Models: Install the top cover assembly (page 179).
IMPORTANT
If the original board was replaced, you must download the emulation
software again. Installing flash memory from the old board onto the new
board does not transfer all operating system software.
8. Load flash memory (page 150).
9. 1500 lpm models only: if the original controller board was replaced, adjust
the coil temperature (page 156).
10. Adjust the hammer phasing (page 148).
11. Adjust the paper out distance (page 144).
12. Using the configuration printout(s) you made as step 1 of the removal
procedure, reset and save the printer configuration(s). (Refer to the
User’s Manual.)
