Chapter 5 Section I: Replacement Procedures
Figure 30. Terminating Resistors, Removal/Installation
Default: 470 Ohm
Alt 1: 220 Ohm
Alt 2: 1K Ohm
Default: 1K Ohm
Alt 1: 330 Ohm
Alt 2: None
RP1
RP2
Controller Board
