Illustrations of Printer Components
223
Item
No.
Part No. Description Notes
1 164212-905 Top Cover Kit, Cabinet Includes mounting hardware
2 131803-901 Window, Top Cover Not visible in Figure 32
3 153640-901 Wireform Paper Path Includes mounting hardware
(Part of 153997-001, Field
Kit, Paper Path, Standard)
4 153084-902 Rear Door Kit Includes mounting hardware
5 153084-903 Front Door Kit Includes mounting hardware
6 141278-901 Caster, with Brake Two at front
7 141278-902 Caster, without Brake Two at rear
8 Ref Logo
