Illustrations of Printer Components
225
Item
No.
Part No. Description Notes
1 158179-901 Passive Stacker Assembly 1000 and 1500 lpm models.
(Not on 500 lpm models or
any printer with the power
stacker.)
2 153503-001 Grommet Kit, Cabinet
3 153778-001 Chain Assembly Kit
4 Ref AC Power Cord
5 Ref Grommet, Power Cord (2) Included in item 2
6 Ref Guide Rail, Stacker Part of item 1
7 151831-001 Clip, Rail, Stacker
8RefScrew (4)
9 175807-001 Tray Assembly, Rear Field Kit, Tray Assembly,
Rear: 175808-001 (Includes
items 1, 6, 7, 8, 9, 10, and
paper tent 173864-001)
10 174392-001 Slide, Ball Bearing, Rear Tray
To Next Page
