Illustrations of Printer Components
227
Item
No.
Part No. Description Notes
1 175093-001 Control Panel Assembly Field Kit Includes mounting bracket
2 152440-901 Cable Assembly, Control Panel Installed with shielding
beads: See Appendix E
3 107961-905 Dashpot Kit Includes ball studs, spring
clips, and mounting
hardware
4 Ref Screw, w/Lock Washer (3) 6-32x.375
5 Ref Screw, w/Lock Washer (3) 6-32x2.00
6 150261-901 Fan Assembly Includes mounting hardware
7 Ref Duct, Air Exhaust
To Next Page
