Illustrations of Printer Components
229
Item
No.
Part No. Description Notes
1 153366-901 Control Panel Assembly
2 Ref Screw, Captive (4)
3 Ref Screw, Captive (2) Part of item 10
4 Ref Lid, Pedestal Model Part of item 10
5RefScrew (2)
6 152440-901 Cable Assembly, Control Panel
7 154288-002 Pedestal Kit w/Tray
8 158635-001 Caster w/Brake, Pedestal (4)
9 Ref Window, Top Cover Part of item 10
10 157337-901 Top Cover, Complete
11 Ref Screw (2) Control panel ground strap
12 Ref Screw (4) 10-32x.625
13 110718-001 Paper Tray
14 157070-001 Fence, Rear Paper Tray
To Next Page
