Illustrations of Printer Components
249
Item
No.
Part No. Description Notes
1RefScrew (2)
2 Ref Card Cage
3 164427-001 Expansion-CT Subassembly CT V3
4 Ref Screw, Captive Part of item 3
5 Ref Standoff, Hex, 3/16 inch, M/F, .813 Lg Part of item 3
6 202485-001 Adapter, Expansion Connector, 60-pin Part of item 3
7 Ref Controller Board
8 Ref Controller Board Connector J111
To Next Page
