Printronix P5000 - Page 284

284
Appendix A
CFX Controller Board (continued)
p2cfxort
August 17, 2001
1
J110
2
3
4
5
6
N FP DATA AVAIL
Front Panel (FP)
470 PF
10%
50V
7
8
FP CLK
N FP LED WR
FP DATA
N FP LCD WR
1
J117
2
3
4
5
6
Paper Stacker
470 PF
10%
50V
7
8
PPR STK STAT0
VCC
NC
9
10
NC
NC
NC
470 PF
10%
50V
470 PF
10%
50V
470 PF
10%
50V
470 PF
10%
50V
PPR STK STAT1
PPR STK CTLO
PPR STK CTL1
1
2
3
J103
Paper Feed Motor
PF 1
PF 2
PF 3
4
PF 4
1
2
3
J116
Shuttle Drive
SHUT A
SHUT B
SHUT C
1
J115
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
UD 1
UD 2
PH REF
UD 3
UD 4
DIODE 1
DIODE 2
DIODE 3
DIODE 4
N COILTEST
CABLE DET
HD SENSE
LDFB
CAUTION: Do not remove or replace the
NVRAM. The NVRAM contains a lithium
battery that can explode if replaced
incorrectly. NVRAM is replaced only at the
factory.
Phase Driver Logic
