List of Illustrations
367
Item
No.
Part No. Description Notes
1 175273-991 Field Kit, Stacker Advance Exchange
Kit
Replacement stacker; not
illustrated
2 204476-001 Washer, Shim, 3/16 inch Bore X .016
inch Thick
3 203251-001 Screw, Hex Skt Btn Hd, Zinc M3X8mm
4 204458-001 Washer, Shim, .125 ID X .010 inch
Thick
5 173818-001 Timing Belt Tensioner Assy, Pwr Stkr
6 170719-001 Paper Deflector
7 202721-901 Clip-On Bearing Part of item 36
8 Ref Screw, Torx, 6-32 x .25 Part of item 36
9 Ref Screw, Shoulder, 10-32 Part of item 36
10 202716-001 Timing Belt
11 156388-001
173726-001
Shaft, Lift, Phase II
Shaft, Lift, Phase III Phase III illustrated here
12 163992-001
173725-001
Pulley, Timing Belt, Phase II
Pulley, Timing Belt, Phase III Phase III illustrated here
13 159398-001 Pulley, Motor
14 150784-901 Clip, Grounding
15
16
158446-001
173530-001
Motor Assembly, Power Stacker
Motor, Stepper, Power Stacker Paper puller motor
20 202713-001 Constant Force Spring
21 175807-001 Tray Assembly, Rear Field Kit, Tray Assembly,
Rear: 175808-001
22 174392-001 Slide, Ball Bearing, Rear Tray
23 173864-001 Tent, Paper, Power Stacker
25 151527-905 Chain Mount outboard of shafts
30 202705-901 Nylon Plug
35 202720-901 Cable
36 173830-001 Stacker Hardware Kit Kit not illustrated
37 Ref Screw, Shoulder, 8-32 Part of item 36
