List Of Messages
81
SHUTTLE JAM
(continued)
9. Run a print test. If the message
appears, replace the controller
board. Record the message and
return it with defective board.
10. Run a print test. If the message
appears, replace the shuttle
frame assembly.
SHUTTLE STALL
See SHUTTLE JAM (page
80).
See SHUTTLE JAM (page 80)
SHUTTLE TYPE
NOT SUPPORTED*
The shuttle type was not
detected at power-up.
1. Power down the printer. Remove
the paper path or top cover to
gain access to the card cage.
Make sure the shuttle data and
power cables are undamaged
and have good connections at the
shuttle and the controller board.
2. Power on the printer. If the
message appears, replace the
controller board. Record the
message and return it with the
defective board.
3. Power on the printer. If the
message appears, replace the
shuttle frame assembly.
SOFTWARE ERROR*
CYCLE POWER
Application software tried to
perform an illegal printer
function or damaged logic
circuits were detected on the
controller board.
1. Cycle power. If the message
appears, power off the printer.
2. Disconnect the input data line
from the host computer. Power
on the printer. If the message
appears, download the emulation
software again (page 150).
3. Cycle power. Run the print job
again. If the message appears,
replace the controller board. If the
message is gone, there is an
application software error.
Request assistance from your
local support group.
Table 2. Message List
Message Explanation Solution
