PRÜFTECHNIK VIBXPERT II User Manual

3-26
VIBXPERT II 05.2012
Options
Entering an Event/Comment
You can record information relating to data collection using pre-
defined events* and freely editable comments. Up to 10 events can be
assigned to every measurement result and every element in a route.
Assigning an event
Prerequisite: The result screen or tree/list view of a route is displayed.
• PresstheMENUkeyandclickon'Event/Comment'(seebelow).
The event editor appears.
• Selecttherelevanteventoreventsinsequence.Theselectionis
listed in the lower event window.
Entering a comment
• IntheeventeditorpresstheMENUkeyagainandclickon"Enter
comment" (see below).
• Enterthecommentandclosethetexteditor.Thecommentisdis-
played below the event window.
Saving
• Tosave,presstheMENUbuttonandclickon'OK'.
A comment icon appears in the result screen next to the channel
name. An event/comment icon appears in the tree/list view next to
therouteelement(seep.3-9).
You can edit, delete and add events in the route later on. Events in
the 'Multimode' cannot be edited or deleted.
Left:
Enter comment
Right:
Open Event Editor
* Import user-defined events via OMNI-
TREND.

Note
Comment icon
Events
Comments
