operation of certain jam conditions, etc.
Upstream Zone / Downstream Zone – Selector to cause the local zone to Accumulate if
a carton arrives and to cause the local zone to be in Accumulate mode upon power up
of the module
Left MDR / Right MDR – Selections for MDR type, speed control, acceleration,
deceleration, etc.
Left MDR / Right MDR – Selector to click to jog the MDR, click again to stop
Left MDR / Right MDR – Visual indicators for various MDR status and diagnostics
information
Diagnostic Window – Click the graphic image to open a details Diagnostics window
Last modified: Aug 05, 2020
Please note that some of the detailed information shown in this figure may be different for
your particular system and that most of these fields will be blank until you actually initiate
communications
*
PULSEROLLER ConveyLinx-Ai2 User's Guide - 1.7
Page 70 of 154

Pulseroller ConveyLinx-Ai2 Specifications

General

Brand	Pulseroller
Model	ConveyLinx-Ai2
Category	Control Unit
Language	English
