Pulseroller ConveyLinx-Ai2 User Manual

7.1.4.3. Speed
The Speed setting value is in meters per second (m/s). The Senergy-Ai motor roller contains data as to its
gear reduction ratio and roller diameter that is readable by the Ai2 Module. EasyRoll then uses this
information to indicate whether the speed you enter is valid for the connected roller.
Setting Speed Value
For our example roller, entering a value of
“0.300” for the speed and clicking Set will
set the speed to 0.3 m/s for the roller. If the
background of the speed entry box remains
white, then the speed is valid for the roller
part number detected by the module
Speed Setting Too High
For our example roller, entering a speed of
2 m/s is over its allowable maximum speed.
The background of the speed entry box will
change to red indicating the speed setting
is too high
Speed Setting Too Low
For our example roller, entering a speed of
0.1 m/s is under its allowable minimum
speed. The background of the speed entry
box will change to blue indicating the speed
setting is too low
Setting the speed too high will result in the motor running at is maximum defined speed
*
Setting the speed too low will result in the motor running at is minimum defined speed
*
PULSEROLLER ConveyLinx-Ai2 User's Guide - 1.7
Page 92 of 154
