7.1.3.1.3. GAP Train Release
All 3 Cartons are Accumulated
When Carton 1 releases and Zone 2’s
GAP time has expired, Carton 2 will
begin to release. Carton 3 remains
accumulated
When Carton 2 releases and Zone 3’s
GAP timer has expired, Carton 3 will
begin to release
When you select Gap Train from the ZPA
Mode drop-down box; the Gap Timer
data entry box and Set button are
enabled. Simply enter the desired time
value and click the Set button to update
the value in the selected Node. In this
example we entered 0.35 seconds
Last modified: Aug 18, 2020
Please note the GAP time does not create a gap or cause any delay when items are in
transportation. The Gap timer is only activated when a given zone accumulates an item and
then it is allowed to release
!
If more than one consecutive zone is configured as Gap Train; then each of these zones
will in turn require that their respective gap timers expire. If the time value is long enough,
the result may appear to be Singulation Release mode or even Singluation Release with
extra time delay. 0.2 to 0.3 seconds are typical values used when you want to help balance
the loading on your power supplies but still have the operation be very close to Train
Release Mode
*
PULSEROLLER ConveyLinx-Ai2 User's Guide - 1.7
Page 77 of 154
