CubiScan 110 Command Set Communications Protocol
52 CubiScan 110
Continuous Measure
This command toggles on or off a continuous measure mode. The
readings transmitted are Length, Height, Width, and Weight. Both
dimensions and counts are transmitted.
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Continuous Msr. Com. Alpha (C) 43h
3 1 End of Text Control (ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
51Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Measure Command Alpha (M) 4Dh
3 1 Acknowledge Alpha (A) 41h
4 1 CubiScan/Host Originated Alpha (C/H) 43h or 48h
5 6 City Code Alpha 000000-ZZZZZZ
11 1 Comma Alpha (,) 2Ch
12 1 Length Identifier Alpha (L) 4C
13 5 Length Numeric 000.0-999.9*
18 1 Comma Alpha (,) 2Ch
19 1 Width Identifier Alpha (W) 57h
20 5 Width Numeric 000.0-999.9*
25 1 Comma Alpha (,) 2Ch
26 1 Height Identifier Alpha (H) 48h
27 5 Height Numeric 000.0-999.9*
32 1 Comma Alpha (,) 2Ch
33 1 Dimension Unit Alpha (E/M) 45h or 4Dh
