Calibration Calibrating Using the Control Panel
CubiScan 110 31
In calibration mode, the weight/dimension units (lb/kg, in/cm) are
automatically set to those last used to weigh and measure a package.
Indicators on the control panel show the current settings.
A zero is displayed in the DIM-FACTOR window to indicate that
the CubiScan is in calibration mode.
Calibrating the Sensors
You will need the 12" x 5" x 3.6" calibration block, supplied with
the CubiScan, to calibrate the sensors. Remove the wrapping from
the calibration block before using it.
To calibrate the sensors using the control panel, proceed as follows.
1. If you calibrated the scale first, turn the power to the CubiScan
off and on, then wait about fifteen seconds for self-diagnostics
to finish before calibrating the sensors.
2. Make certain that the CubiScan platform is free of all objects.
3. Press on the control panel. The LENGTH, WIDTH, and
HEIGHT windows display
0.0, and the DIM-FACTOR window
displays a command code of
1.
4. Make sure there is nothing on the CubiScan platform, and press
<msr>.
Do not disturb the CubiScan until the LENGTH window dis-
plays
12.0, and the DIM-FACTOR window displays a command
code of
2.
5. Place the calibration block on the platform and slide the 12"
side against the back panel with the end against the left length
sensor (when looking from the front) as shown below.
in
cm
--------
