Setting Up the Back Panel Setup

8 CubiScan 110

NOTE

A power strip (not included) is recommended for turning power off

and on.

Setting Up the Back Panel

Take the following steps to attach the back panel and connect the

sensor cables.

1. Using the 5 mm hex wrench provided, remove the four socket

head cap screws from the back of the CubiScan.

☞

Figure 4

Removing the Back Cap Screws
