Removing the Controller Box Maintenance
40 CubiScan 110
vent the possibility of interference. To clean, gently blow dust from
the gold foil surface.
Removing the Controller Box
If you suspect a problem with the CubiScan 110 controller, first
review the Troubleshooting chapter and take any recommended
action. If the problem persists, contact Quantronix Technical Assis-
tance at (801) 451-7000 for assistance.
If Quantronix recommends removing the controller box and return-
ing it for service, proceed as follows.
1. Turn off the power switch (on the power strip), and disconnect
the power cord from the power strip.
2. Tip the front of the CubiScan up enough to reach under and
loosen the thumb screws, and remove the RS-232 serial cable
from the right side of the controller box.
3. To access the controller box, remove the four Allen head screws
on the corners of the controller box mounting plate using the 2.5
mm Allen wrench. The control panel is in the center of the
mounting plate, and the mounting plate is attached to the front
of the CubiScan base.
4. Slide the controller box forward out of the base. Be careful not
to pull on the attached cables. The cables should be long enough
to allow the controller box to slide out far enough to remove the
cover.
CAUTION
The gold foil screen on the front of the sensor is delicate. Do not
use high pressure air or water lines to clean the surface of the gold
foil and do not touch it with fingers, tools, or brushes. Doing so
may result in damage.
