Communications Protocol TCP/IP Communications Setup Command Set
CubiScan 110 73
Read IP Address
This command is used to read the current IP address setting from the
CubiScan 110.
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Read Command Alpha (~) 7Eh
3 1 IP Address Command Alpha (I) 49h
4 1 End of Text Control (ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
6 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Read Command Alpha (~) 7Eh
3 1 IP Address Command Alpha (I) 49h
4 1 Acknowledge Alpha (A) 41h
5
7-15
or n
IP Address Alpha
(0.0.0.0) to
(255.255.255.255)
5+n 1 End of Text Control (ETX) 03h
6+n 1 Carriage Return Control (CR) 0Dh
7+n 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Read Command Alpha (~) 7Eh
3 1 IP Address Command Alpha (I) 49h
4 1 Neg. Acknowledge Alpha (N) 4Eh
5 1 End of Text Control (ETX) 03h
