CubiScan 110 Command Set Communications Protocol
60 CubiScan 110
* This field may contain underscores, dashes, or tildes indicating an
under, unstable, or over error condition, respectively. Leading
spaces (20h) will be used when the actual data does not fill the
entire field.
Scale Calibration
This function is required when the load cell is replaced, when a new
controller is installed, or for routine calibration. This command
causes the CubiScan to reply with a scale calibration code. This
command must be issued THREE times to complete scale calibra-
tion. Scale calibration codes are defined below.
51
Corner Sensor / Measure /
Zero Error
Alpha (C/M/Z) 43h or 4Dh
6 1 End of Text Control (ETX) 03h
7 1 Carriage Return Control (CR) 0Dh
8 1 Line Feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Scale Calibration Alpha (S) 53h
3 6 Test Weight Value Numeric 050.00-100.00
9 1 End of Text Control (ETX) 03h
10 1 Carriage Return Control (CR) 0Dh
11 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Scale Calibration Alpha (S) 53h
3 1 Acknowledge Alpha (A) 41h
To Next Page
