Setup Adjusting the Shipping Bolts

CubiScan 110 11

7. Route the height sensor cable up the channel on the back panel,

and insert the plug into the socket on the height sensor (see

Figure 7).

Adjusting the Shipping Bolts

Five shipping bolts are located on the CubiScan base to anchor the

scale to the base. The bolts must be tightened after shipping for

proper operation of the scale.

1. Gently tip the CubiScan onto the back panel to expose the bot-

tom of the scale.

Figure 7

Plugging in the Height Sensor Cable
