Ethernet (TCP/IP) Cable Pin Assignments Communications Protocol

50 CubiScan 110

The following table shows the parameters for asynchronous com-

munications through the RS-232 serial cable.

Ethernet (TCP/IP) Cable Pin Assignments

The CubiScan 110 Ethernet port uses the 10-BaseT TCP/IP commu-

nications protocol. The following table shows the Ethernet RJ-45

connector pin assignments.

Asynchronous

Communication Parameters

Baud Rate 9600

Parity None

Data Bits 8

Start Bits 1

Stop Bits 1

RJ-45 Connector Pin Assignments

Pin Signal Description

1 TD+ Transmit Data

2 TD- Transmit Data

3 RD+ Receive Data

4 NC No Connection

5 NC No Connection

6 RD- Receive Data

7 NC No Connection

8 NC No Connection
