Calibration Calibrating Using the Control Panel
CubiScan 110 29
Preparing the CubiScan for Calibration
To prepare the CubiScan 110 for calibration, proceed as follows.
1. Turn off the power switch (on the power strip), and disconnect
the power cord from the power strip.
2. Tip the front of the CubiScan up enough to reach under and
loosen the thumb screws, and remove the RS-232 serial cable
from the right side of the controller box.
3. To access the controller box, remove the four Allen head screws
on the corners of the controller box mounting plate using the 2.5
mm Allen wrench. The control panel is in the center of the
mounting plate, and the mounting plate is attached to the front
of the CubiScan base.
4. Slide the controller box forward out of the base. Be careful not
to pull on the attached cables. The cables should be long enough
to allow the controller box to slide out far enough to remove the
cover.
5. Remove the cover of the controller box by removing the four
screws (one at each edge) and sliding it back.
6. Locate the DIP switch inside the controller box, as shown
below, and locate switch number 6 on the DIP switch.
