Communications Protocol CubiScan 110 Command Set
CubiScan 110 61
Scale Calibration Code Descriptions:
SA01 Clear the CubiScan
SA02 Place Test Weight in Corner
SA03 Scale Calibration Complete
Test
This command causes the CubiScan to reply with an error code. A
response of TA00 means that the CubiScan is ready and responding
to transmissions from the host. If the host receives no response from
the control unit after sending this command, an error condition
exists in the communications between the host and controller.
4 2 Identifier Numeric (00-99)
6 1 End of Text Control (ETX) 03h
7 1 Carriage Return Control (CR) 0Dh
8 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Scale Calibration Alpha (S) 53h
3 1 Neg. Acknowledge Alpha (N) 4Eh
4 1 End of Text Control (ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
6 1 Line Feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Self Test Command Alpha (T) 54h
