CubiScan 110 Command Set Communications Protocol

54 CubiScan 110

Dimension Calibration

This function is required when one of the sensors is replaced or

moved, when a new controller is installed, or for routine calibration.

This command causes the CubiScan to reply with a dimension cali-

bration code each time it is issued. This command must be issued

SIX times to complete sensor calibration. Dimension calibration

codes are defined below.

Pos Len Description Type Range ASCII

Command Format

1 1 Start of Text Control (STX) 02h

2 1 Dim.Calibration Alpha (D) 44h

3 1 End of Text Control (ETX) 03h

4 1 Carriage Return Control (CR) 0Dh

5 1 Line Feed Control (LF) 0Ah

Acknowledge Format

1 1 Start of Text Control (STX) 02h

2 1 Dim. Calibration Alpha (D) 44h

3 1 Acknowledge Alpha (A) 41h

4 2 Identifier Numeric (00-99)

6 1 End of Text Control (ETX) 03h

7 1 Carriage Return Control (CR) 0Dh

8 1 Line Feed Control (LF) 0Ah

Negative Acknowledge Format

1 1 Start of Text Control (STX) 02h

2 1 Dim. Calibration Alpha (D) 44h

3 1 Neg. Acknowledge Alpha (N) 4Eh

4 1 End of Text Control (ETX) 03h

5 1 Carriage Return Control (CR) 0Dh

6 1 Line Feed Control (LF) 0Ah
