Communications Protocol CubiScan 110 Command Set

CubiScan 110 55

Dimension Calibration Code Descriptions:

DA01 Clear the CubiScan

DA02 Place 12" target against left sensor facing RIGHT

DA03 Place 12" target against right sensor facing LEFT

DA04 Place 12" target against back panel facing FRONT

DA05 Place 12" target against back panel facing UP

DA06 Dimension calibration complete

Dimension Units

This command is used to set the dimension units to either English

(inches) or metric (centimeters) mode.

Pos Len Description Type Range ASCII

Command Format

1 1 Start of Text Control (STX) 02h

2 1 Dim. Unit Command Alpha (") 22h

3 1 English or Metric Alpha (E/M) 45h or 4Dh

4 1 End of Text Control (ETX) 03h

5 1 Carriage Return Control (CR) 0Dh

6 1 Line Feed Control (LF) 0Ah

Acknowledge Format

1 1 Start of Text Control (STX) 02h

2 1 Dim. Unit Command Alpha (") 22h

3 1 Acknowledge Alpha (A) 41h

4 1 End of Text Control (ETX) 03h

5 1 Carriage Return Control (CR) 0Dh

6 1 Line Feed Control (LF) 0Ah

Negative Acknowledge Format

1 1 Start of Text Control (STX) 02h

2 1 Dim. Unit Command Alpha (") 22h

Questions and Answers:
